Operation and Maintenance of Hydraulic Systems in Oil & Gas

Introduction:

This Principles, Operation, and Maintenance of Oil and Gas Hydraulic Systems training seminar provides participants with comprehensive knowledge and skills on hydraulic power systems. It is an interactive educational session designed to help participants learn how the different parts of a typical hydraulic system function and connect with one another.

Participants will handle the most important groups of hydraulic components, including direct- and pilot-operated relief valves, pressure-reducing valves, directional control valves, positive-displacement pumps, variable-displacement pumps, and accumulators. The seminar also covers basic hydraulic circuits commonly present in industrial hydraulic systems.

Furthermore, the training addresses hydraulic principles as applied to mechanical maintenance, hydraulic fluids, and their types and properties. This seminar empowers participants to diagnose and assess faults and damages in the primary circuit elements of the hydraulic system for maintenance purposes, adjust control valves, and conduct verification tests of hydraulic circuits concerning functionality and safety.

Objectives:

At the end of this Principles, Operation, and Maintenance of Oil and Gas Hydraulic Systems course, participants will be able to:

• Outline the various constituents of hydraulic systems.
• Assess the effect of hydraulic fluids on the components.
• Explain and utilize hydraulic symbols.
• Follow correct procedures for operating hydraulic systems.
• Define maintenance and troubleshooting procedures applicable to the entire hydraulic system.

Training Methodology:

• Case studies
• Group discussions
• Practice sessions
• Simulator training
• Site visits
• Situational exercises

Course Outline:

Unit 1: Basic Concepts of Hydraulics and Hydraulic Fluids

• The principle of Pascal
• The Reynolds number in hydraulic system components
• People and machines: Filters, reservoirs, and accumulators
• Closed and open loop systems
• Properties of hydraulic fluid
• Types of hydraulic fluids
• Fluid selection
• Problems related to fluids

Unit 2: Hydraulic Pumps & Actuators

• Types and performance of hydraulic pumps
• Hydraulic pumps with variable and fixed displacements
• Hydraulic gear pumps
• Hydraulic vane pumps
• Hydraulic piston pumps
• Pressure compensator and load sense control systems
• Construction of hydraulic cylinders
• Construction of hydraulic motors

Unit 3: Control Valves

• Control valve classification
• Control valves: Direct-acting and pilot operated
• Control valves: Pressure control
• Control valves: Directional control
• Control valves: Flow control
• Meter in and meter out

Unit 4: Operation and Hydraulic Circuits

• Operator duties
• Schematic diagram of hydraulic components
• Operational procedures for regenerative circuits
• Solar circulator counterbalance circuits
• Decompression circuits
• Different types of machines utilizing hydraulic circuits

Unit 5: Maintenance and Troubleshooting of Hydraulic Systems

• The various hydraulic circuits and their flow charts
• Defects and troubleshooting of different components of hydraulic systems
• Purpose and difference between assembling and disassembling a hydraulic unit
• Procedure for inspection and testing of hydraulic circuits
• Operation and maintenance of hydraulic systems
• Grouping cases
• Course summary and feedback
